LOW VOLTAGE POWER CABLES

Red Sea Cables Company offers an extensive range of 0.6/1.0kV single-core and multi-core power cables. These cables have indoor and outdoor applications in power and petrochemical plants, utility buildings, electrical equipment, and more. We use the highest quality raw materials and the latest manufacturing techniques to produce these cables.



Technical Specifications:

•   Electrical low voltage cables complying with IEC 60502-1 BS 5467. Our products tested at internationally reputable labs, all cables are Flame Retardant to IEC 60332-1 Vertical Flame Propagation Test.

Conductor:

•   High conductivity soft annealed copper according to BS EN 60228, Class 2 stranded and Class 5 flexible conductor and Stranded aluminum conductor Class2. Conductor can be offered with round, round compacted and  sectored shape.

Insulation:

•   Polyvinyl chloride (PVC) & Cross-linked polyethylene (XLPE) with Maximum service temperature 90ºC.

Armoring:

•   Aluminum Wire Armored “AWA” or Aluminum Tape Armored “ATA” for single core cable.

•   galvanized steel wire “SWA” or galvanized double steel tape “STA" for multi core cable.

Outer Sheathing:

•   Polyvinyl Chloride (PVC ST2)

Special Requirements:

•   High fire performance, Flame propagation tests: IEC 60332-3

•   Sunlight & UV Resistant

•   Water resistance

•   Anti-termite & Anti-Rodent resistant.

•   Special color for insulation and outer sheath

•   Special outer sheath material: PVC(FRLS), LLDPE, LDPE, MDPE and HDPE

•   Different packing options are available

Application

• These cables are suitable for direct burial or for installation on trays or in ducts.
